Applications
instrument for rebar detection, cover depth and rebar diameter measurements
Technical Data
Measuring Range | See graph on previous page for maximum range relative to bar diameter. |
Power Supply | |
Power source | 2 x 1.5 V AA (LR6) batteries |
Voltage range | 3.6 V to 1.8 V |
Current Consumption | |
Power on, backlight off | ~ 50 mA |
Power on, backlight on | ~ 200 mA |
Sleep mode | ~ 10 mA |
Power off | < 1 μA |
Battery Lifetime | |
Backlight off | > 50 h |
Backlight on | > 15 h |
Time Outs | |
Sleep mode | 30 s |
Auto shut down | 120 s |
Environmental Conditions | |
Temperature range | -10º to 60º C (14º to 140º F) |
Humidity range | 0 to 100% rH |
Protection class | IP54 |
Standards and Regulations Applied | BS1881 part 204; DIN1045; SN 505 262; DGZfP B2 |
Data Storage (Profoscope+ only) | 49’500 measurements total (500 objects with 99 measurements) Compatibility ProfoLink: Windows 2000, XP, Vista, 7 |
